Stivuitor electric Baoli CPD20J, 2T, 3M

Electrostivuitor Baoli CPD20J, 2T, 3M Caracteristici tehnice: Producator: Baoli Denumire model: CPD20J Propulsie: baterie Capacitate de ridicare (kg): 2000 Centrul de incarcare (mm): 500 ÃŽnaltimea de ridicare h (mm): 3000 ÃŽnaltime de ridicare cursa libera h4(mm): 140 Dimensiunile furcilor L x W x T (mm): 1070 x 120 x 40 Distanta extensie furci min. / max. b4(mm): 240/1040 Unghi inclinare catarg inainte / inapoi &alpha, / &beta, grade(o): 6 / 10 Iesire in fata X(mm): 459 Dimensiuni gabaritice Lungime echipament pana la fata furcilor l1(mm): 2349 Latimea totala b1(mm): 1265 ÃŽnaltime minima catarg coborat h1(mm): 2040 ÃŽnaltime maxima catarg ridicat h3(mm): 4240 ÃŽnaltime de ridicare cursa libera h2(mm): 2125 Raza minima de intoarcere R(mm): 2050 Latime culoar de lucru unghi drept minim RAXA(mm): 3715 Viteza de deplasare, incarcat / descarcat (km/h): 14 / 12 Viteza de ridicare, incarcat / descarcat (mm / s): 420 / 310 Inclinare max. incarcat (%): 10 Greutate proprie(kg): 4160 Forta maxima de tragere(incarcat) (KN): 8 Sasiu Roti fata: 23x9-10-16PR Roti spate: 18x7-8-14PR Ecartament fata b2(mm): 1040 Ecartament spate b3(mm): 950 Ampatament Y(mm): 1500 Garda la sol minima catarg incarcat / descarcat M(mm): 105 / 85 Garda la sol minima sasiu incarcat / descarcat F(mm): 140 / 120 Tensiune baterie(V): 48 Capacitate nominala (Ah): *630/700 Motor de antrenare (kW/rpm): 8 / 1300 Motor hidraulic (kW/rpm): 15 / 2200 Controller: SME AC controller Italian
